Sintered Mesh

Short Description:

The multi-layered structure of sintered mesh ensures a high level of filtration efficiency. It can remove particles of various sizes and help achieve precise filtration results. The sintered mesh has a strong mechanical structure that can withstand high pressures and stresses without deformation or damage. This makes it ideal for use in demanding applications that require high strength.

Send email to us

Product Detail

Product Tags

Introduction

The common and standard combination is 5-layer sintered wire mesh. It is combined by five different layers or multi-layers of stainless steel wire mesh and then sintered together by vacuum sintering, compression and calendering, creating a porous product. This creates a unique material offering excellent mechanical properties. It is ideal material for purification and filtration.

Display

Specification

● Material: Standard material SUS304 (AISI304), SUS316 (AISI316), SUS316L (AISI316L), Alloy Steel Hastelloy, Monel, and Inconel.
● Standard Size: 500 × 1000 mm, 600 × 1200 mm, 1000 × 1000 mm, 1200 × 1200 mm, 300 × 1500 mm.
● Fabrication: easily formed, sheared, welded and punched.
● Filter rating : 1 - 300 μm

Characteristic

1. Steady filter rating

2.High strength, Good rigidity

3.Strong corrosion resistance and heat resistance

4. Good processing, welding and assembly performance

5.Easy to wash, especially to reverse wash.

Application

Petrochemical industry, Metallurgical machinery, Energy and environmental protection, Textile and Electric Power, Aerospace, Medicine and other industrial fields.
